MODEL 1.2V2
CONFIG:
- antenna post;
- device module with station control system;
- Ku-band transmitting and receiving equipment;
- field power supply;
- set of connecting cables;
- reserve set of instruments and tools (single);
- set of operational documents.
The satellite communication station is designed for organizing a high-speed data transmission channel by communicating and broadcasting spacecrafts for civil purposes in Ku- and C-frequency bands located on geostationary orbit.
Technical specifications
AURIGA 1.2V2
- Frequency range, MHz:
- for receiving: 10950.0 - 11750.0;
- for transmitting: 13750.0 - 14500.0.
- Frequency grid step, kHz: 10;
- Polarization isolation, dB, not less than: 30;
- Transmitter power, W, not less than: 6;
- Effective isotropically radiated power, dB W, not less than: 49;
- Speeds of signals, Kb/sec: 32 - 4096;
- Interfacing with terminal equipment: Ethernet 10/100 Base-T (IEEE 802.3);
Power supply:
- industrial network with a voltage of 220 V 50 Hz;
- standard field power supply 24 V.
- Power consumption, W, no more than: 80;
- Overall dimensions (W × H × D), mm: 980x860x600;
- Full weight, kg: 112.8;
- Running time before failure, hours: 5000;
- Service life time, years: 7;
MODEL 1.2VA
Antenna post consists of:
- antenna reflector 1.2m on a motorized base
- magnetic compass
- engine control unit
- position sensors
- Ku-band microwave equipment
- C-band microwave equipment
- station control unit
- satellite modem
- operator’s workstation
- VoIP gateway
- interface converter Eth/E1 Astarta iBase TDMoIP gateway
- intercom unit
- power supply
A mobile dual-band satellite station is designed to organize high-speed satellite communication channels in C and Ku-bands using VSAT technology through communication spacecrafts located on geostationary orbit. A station can be operated in difficult climatic conditions.
Technical specifications
MODEL 1.2VA
- Ku-band operating frequency range:
- for transmitting 13.75-14.5 GHz
- for receiving 10.95-11.7 GHz
- C-band operating frequency range:
- for transmitting 5.725-6.225 GHz
- for receiving 3.4-4.2 GHz
- frequency grid step 10 kHz
- Information transfer speed:
- Ku-band 30-2048 kbit/sec
- C-band 32-1024 kbit/sec
- Working conditions:
- relative air humidity 98% and + 35°С temperature;
- ambient temperature from -40°С to + 50°С;
- reduced atmospheric pressure up to 450 mm Hg;
- wind speed up to 20 meters/sec.
MODEL A90Ku
CONFIG:
- Gyro-stabilized antenna post with radio-transparent shelter;
- Device stand (19’):
- Antenna control unit;
- Satellite modem;
- Ethernet switch;
- Router;
- Uninterruptable power source.
The ship satellite station is designed to organize a duplex high-speed satellite communication channel in Ku-band in directions "ship-to-shore", "ship-to-ship" by using VSAT technology through satellites-repeaters located on geostationary orbit.
- withstands wind loads up to 216 km / h in all directions;
- ensures normal operation under shockwave conditions.
Technical specifications
MODEL A90Ku
Operating frequency range, MHz:
- Ku-band: 10950.0 - 12750.0;
- C-band: 13750-14500.0.
- Antenna gain, dB:
- Ku-band: 41.1;
- C-band: 42.1;
- Polarization: linear;
- Cross-polarization isolation, dB, not less than: 30;
Radio frequency equipment:
- Ku-band: Low noise block (DRO LNB) included;
- C-band: Block up convector (BUC) 3 * Watt.
- Dimensions (W × H), cm: 111 x 114;
- AP weight, kg: 65;
- Antenna pointing: automatic;
Antenna working angles sectors, degrees:
- elevation angle from -10 to 90;
- azimuth - unlimited.
- Repeater tracking during lateral rolling, degrees: from - 120 to +120;
- Maximum tracking speed, deg/sec: up to 30;
- AC power supply: 24 V from the antenna control unit;
- Power supply for control unit and satellite modem: 220V, 50Hz;
- Operating temperature range, degrees C: from -30 to + 50;
- Power consumption, VA: 100.
MVBK
CONFIG:
- satellite communication station 1.2V2;
- mobile telecommunication complex;
- set of additional equipment for the C-band;
- field power supply;
- set of video sources equipment;
- set of mounting parts;
- portable operator’s workstation;
- electrical unit;
- tent for equipment;
The mobile video broadcasting kit is designed for organizing video broadcasting on the ground, as well as video conferencing in open mode through spacecrafts of the broadband satellite network.
Technical specifications
MVBK
Maximum speed of satellite communication channel for receiving:
- for receiving: up to 54 Mbit/sec;
- for transmitting: up to 4 Mbit/sec.
Frequency range:
- for receiving: 3.400-3.900 GHz; 10.95-11.75 GHz;
- for transmitting: 5.725-6.225 GHz; 13.75- 14.5 GHz.
Transmitter power:
in Ku-band: 6 W;
in C-band: 30 W.
Transmitter power, W, not less:
in Ku-band: 6;
in C-band: 30.
Routing and switching equipment:
- Ethernet 10/100/1000Base-T - 4 ports;
- G.703/G.704 - 2 ports;
- PoE 10/100BaseT (802.3at) - 4 ports r.
Video source equipment:
- IP cameras (PTZ) - 2 pieces:
- rotation angle range +/- 180 degrees;
- range of tilt angles +/- 90 degrees;
- zoom 18x;
- maximum resolution 1920x1080;
- shots rate not less than 25 shots/sec;
- operating temperature range from -20°С to + 40°С;
- class of dust and moisture protection IP65.
Autonomous power supply source: diesel generator set with a single-phase voltage of 220 V and a frequency of 50 Hz with a power of 2.7 kW.
